Main Performance
| Number of Contact Pins | 2~7 cores |
| Contact Resistance | <20 mQ |
| Insulation Resistance | >2000MΩ (normal), >1000MΩ (environmental testing) |
| Dielectric Voltage | ≤1500V DC, 1 min |
| Single-Core Current Rating | ≤20A |
| Insertion Loss | 1.2dB standard / 0.6dB low loss (1310nm) |
| 1.0dB standard / 0.5dB low loss (1550nm) | |
| Mechanical Life | >500 cycles |
| Factory Test Pressure | Standard lateral 5MPa, customizable up to 20MPa lateral pressure, customizable receptacle with longitudinal waterproofing |
| Operating Temperature | -45°C to 90°C |
| Connector housing | Standard stainless steel 316L, customizable titanium alloy TC4; |
| Optical contact | Zirconia ceramic pins |
| Electrical contact | Gold-plated brass |
| Sealing end cap | Stainless steel 316L |
| Cable | Polyurethane cable or rubber-sheathed cable |
Connector Arrangement
|
Number of cores: 2 optical/electrical Single-core current rating: 20A Operating voltage: 1000V DC/AC rms Dielectric voltage: 1500V DC Insertion loss: ≤1.0dB@1550nm |
Number of cores: 4 optical/electrical Single-core current rating: 10A Operating voltage: 500V DC/AC rms Dielectric voltage: 1500V DC Insertion loss: ≤1.0dB@1550nm |
Number of cores: 7 optical/electrical Single-core current rating: 5A Operating voltage: 500V DC/AC rms Dielectric voltage: 1000V DC Insertion loss: ≤1.0dB@1550nm |
| Note: Customization is available to support optical, electrical, and RF transmission requirements with different core counts. | ||
Dimensions Of The External Structure
Plug shape
OE25M/05MTEXFY Vertical Tail Attachment Configuration
Outlet shape
OE25M/05MI Outlet
OE25M/05MF Outlet
Sealing Cap Profile
